Commercial

Big Audience, Big Impression.

Because style isn’t just for home anymore.

Custom registers and access panels for that special touch, as well as decorative and stylish air return covers

Made for the trade.

SteelCrest understands the unique needs of commercial HVAC requirements.

Our catalog boasts air distribution products and access panels, tailored for your project, including ceiling, wall & floor vents, grilles, and diffusers designed for commercial environments.

Specify it and we’ll build it right here in our USA manufacturing plant. Architects, engineers, and interior designers benefit from our ability to accommodate virtually any specification. Harness the full potential of our many options and get exactly what you imagined.

View our Example GRD Schedule

Specification options:

addMaterial Type
  • Carbon Steel
  • Galvanized Steel
  • Corten Steel
  • 5052 Aluminum Alloy
  • 6061 Aluminum Alloy
  • SAE 304 Stainless Steel
  • SAE 316L Stainless Steel
  • Yellow or Red Brass
  • Copper
  • C220 Commercial Bronze
  • C28000 Muntz Metal

addMaterial Thickness
  • 14 Gauge (.0747”)
  • 11 Gauge (.1196”)
  • 3/16-Inch (.1875”)
  • 1/4-Inch (.25”)
  • 5/16-Inch (.3125”)
  • 3/8-Inch (.375”)

addFinishes
  • Raw with sanded/deburred finish
  • Single-Coat Powder Coat
  • Powder Coat with Secondary Clear Coat
  • Primer Powder Coat for Paint-to-Match Spec
  • Brushed Finish
  • Polished Finish
  • Oxidized Finish
  • Clearcoat

RAL Finishes/Custom Finishes

Matching specified RAL colors and/or paint manufacturer paint finishes can be done but can present issues that can make it difficult.

For instance, even if a powder coat finish is ordered to match the name/number of the specified finish, often times the percentage of gloss and/or texture will likely vary from a given manufacturer’s color swatch.

Because of this variance, we recommend ordering your products with a zinc-rich primer powder coat, which can be easily painted to match by the project’s onsite painting contractor.

Care should be taken to remove specified installed accessories, like dampers, air deflectors, and concealment louvers, prior to painting.

addDesigns

SteelCrest does not limit you to a single collection of designs, but offers you any design from any source you specify.

Specified designs can be modified, as needed, to meet or exceed project airflow requirements, as specified by project engineers.

addSizes

Single-piece grilles can be made as large as 117x57 inches, and as small as 3x3 inches. However, shipping restrictions can be a barrier to larger pieces being transported outside our local 85040 zip code.

Often times, larger pieces can be fabricated in 2 or 3 piece configurations with final joining of pieces in the field prior to installation.

addAirflow Characteristics

Because each unique design can often be altered by shrinking or expanding the design, or modifying the geometry, airflow characteristics can vary greatly.

SteelCrest does have extended airflow ratings, including CFM, pressure drop, throw distances, and noise ratings, on many designs.

Please inquire for more information regarding your requested project and how this data will be affected depending on how design is altered.

addTypes of Airflow Distribution

addAvailable Accessories for Airflow Distribution Products
